Coffee Grind Size Converter

Interactive grind size chart with clicks and levels guide for adjusting your grinder between Espresso, V60, French Press and more. Technical micron mapping for all extraction methods.

0μm 400μm 800μm 1200μm 1600μm

Tastes bitter, dry or astringent?

You are over-extracting. Grind coarser so water flows faster and extracts fewer bitter compounds.

Grind coarser

Tastes sour, salty or watery?

You are under-extracting. Grind finer to increase contact surface and extract more sugars and body.

Grind finer
Utilities Studio

Want this utility on your website?

Customize colors and dark mode for WordPress, Notion or your own site.

Frequently Asked Questions

Why doesn't the same grind setting work for all coffees?

Bean density varies by roast level and origin. A light roast is typically denser and requires a finer grind to extract properly, while a dark roast is more porous and needs a coarser setting.

How do I know whether to grind finer or coarser?

Let your taste guide you: if the coffee tastes bitter and dry, grind coarser so the water flows faster. If it tastes sour, salty or watery, grind finer to increase the contact surface area.

What is 'channeling' and how does grind affect it?

Channeling occurs when water finds a path of least resistance through the coffee bed. An uneven or inappropriate grind for the pressure — especially in espresso — encourages this problem and ruins extraction.

Can I use this chart with a blade grinder?

Blade grinders produce non-uniform particles — fine powder and large chunks simultaneously. The micron values are indicative, but actual results will vary significantly compared to a burr grinder.

What does grinder uniformity mean in the visualization?

The particle distribution shown simulates the real uniformity of each grinder. A Comandante C40 with 0.95 uniformity produces very consistent particles; a Hario Skerton with 0.40 shows much more size variation.

# The Physics of Grind Size: Why Particle Size Changes Everything

When you grind coffee, you are not just reducing bean size. You are defining the contact surface area available for water to dissolve flavor compounds. Too fine, and the water over-extracts bitter compounds. Too coarse, and water passes through without enough resistance, producing a weak and sour cup. The grind converter gives you the exact range for each method.

What determines the correct grind size?

Extraction method: Pressure, contact time and filter type dictate the optimal micron range for each brewing method.
Grinder uniformity: A high-end burr grinder produces homogeneous particles; a blade grinder generates fine powder and large chunks simultaneously.
Bean freshness: Freshly roasted coffee contains more CO2 and may need a slightly coarser grind than the same coffee aged a few weeks.
Taste calibration: The palate is the final instrument. The chart is your starting point; flavor is your destination.
Method Microns Tactile reference Contact time
Ibrik (Turkish)100-300 μmTalc / Fine flour3-5 min boiling
Espresso300-500 μmFine salt25-30 sec
Moka / AeroPress500-700 μmTable salt3-4 min
V60 / Filter700-900 μmGranulated sugar2:30-3:15 min
Chemex / Clever900-1200 μmCoarse sand3:30-4:30 min
French Press1200-1500 μmCoarse salt4 min immersion
Cold Brew1500+ μmPeppercorns12-24 h cold
Golden rule for new coffees

When you open a new coffee, always start at the midpoint of the recommended range for your method. From there, adjust by taste one click at a time. Keep notes on each adjustment to build a reference log of your favorite coffees with each grinder.
